12″ powered coaxial stage monitor

Description

The MON 12 A G3 is part of an entirely newly developed family of powered stage monitors for high performance. The MON G3 Series incorporates the advanced technology and premium materials found in high-end monitors typically rented by professionals, making this quality available to everyone. These include, for example, advanced coaxial loudspeakers with integrated 50° x 90° CD horn, which ensure the acoustic ideal of a true point source and thus outstanding audio characteristics even at short listening distances. Besides this, the series offers a high-level of robustness, a comprehensive set of features and the elegant LD Systems design.
For decades, 12″/1″ stage monitors have been the golden mean when it comes to sonority, sound pressure and portability. With coaxial design, smart electronics and a professional look, the MON 12 A G3 brings this concept into the “modern age”. The ideal dispersion geometry of 50° x 90° for monitor use or 90° x 50° for FOH use make it a multi-talent that offers the right solution for a wealth of different tasks.
Both the signal (XLR/jack combo) and the power connection (PowerCON compatible) can be looped through. This allows for elegant, tidy cabling in multi-monitor set-ups or for distributed sound reinforcement.

slide 1 of 2



Specifications

General

Product type
Stage monitors

Type
Powered

Color
Black

System output (RMS)
300 W

System output (Peak)
1200 W

Max. SPL Average (Sine burst)
120 dB (100 Hz – 12 kHz, fullspace @1m, 10% THD)

Max. SPL Peak (Sine burst)
127 dB (fullspace @1m, 10% THD)

Frequency response (-3 dB)
68 – 18000 HZ

Frequency response (-10 dB)
55 – 20000 Hz

Crossover frequency
1400 Hz

Monitor angle
33°

Dispersion (H x V)
50° x 90°

Width
425 mm

Depth
453 mm

Height
315 mm

Features
3-band EQ (High, Mid, Low), Delay line, Notch filter

Weight
17,4 kg

Low/mid woofer

Low/mid Woofer dimensions
12 ”

Woofer dimensions (mm)
304.8 mm

Woofer magnet
Ferrite

Woofer brand
Custom-made

Woofer type
Coaxial loudspeaker

Woofer voice coil
2.5 ”

Woofer voice coil (mm)
65 mm

Cabinet construction
Bass Reflex

Cabinet material
15 mm Birch Plywood, 15 mm MDF

HF

Horn
CD Horn

Tweeter dimensions
1 ”

Tweeter dimensions (mm)
25.4 mm

Tweeter magnet
Ferrite

Tweeter brand
Custom-made

Tweeter voice coil
1.75 ”

Tweeter voice coil (mm)
44.45 mm

Amplifier module (integrated)

Amplifier
Class D

Protection circuits
Multiband limiter, over voltage, over-current, thermal overload

Operating Temperature
0 – 40 °C

Humidity Range
< 80 % ( non-condensing )

Fuse
T4AL 250 V

Controls
On / off switch, Rotary/push encoder

Indicators
LC display

Operating voltage
SMPS

Operating voltage
100 V AC – 240 V AC, 50 – 60 Hz

Power consumption
150 W

Power in / out
PowerCON compatible

Line inputs
2

Line input connectors
6.3 mm jack, XLR – combo

Line thru
2

Line through connector
XLR
