Professional 4-Pole Panel Mount Audio Socket
A high-quality 3.5mm 4-contact (TRRS) panel mount jack designed for reliable audio and signal transmission in professional and OEM applications.
Built with a durable polyamide housing, brass sleeve, and gold-plated contacts, this connector ensures excellent conductivity, corrosion resistance, and long service life — ideal for audio equipment, control panels, and custom AV builds.
🔧 Key Features
-
4-Pole (TRRS) Configuration – Stereo audio + microphone or auxiliary channel
-
3.5mm Standard Jack – Compatible with headsets and portable audio devices
-
Panel Mount (M8 Thread) – Secure chassis installation with hex nut
-
Gold-Plated Contacts – Superior signal integrity & corrosion resistance
-
Polyamide Housing (PA) – Lightweight and durable
-
Solder Termination – Strong mechanical and electrical connection
📐 Technical Specifications
| Specification | Details |
|---|---|
| Connector Type | 3.5mm Jack (Female) |
| Number of Poles | 4 |
| Mounting Type | Panel Mount |
| Thread | M8 x 0.75 |
| Contact Resistance | 50mΩ Max |
| Insulation Resistance | 100MΩ @ 500V DC Min |
| Dielectric Strength | 500V AC (1 minute) |
| Contact Plating | Gold |
| Contact Termination | Solder |
| Housing Material | Polyamide |
| Insulation Tube | PVC |
| Colour | Grey |
🎧 Typical Applications
-
Headset input/output panels
-
Intercom systems
-
AV wall plates
-
Rack panel builds
-
Portable audio equipment repairs
-
DIY electronics & embedded projects
📏 Mechanical Dimensions (Approx.)
-
Front Diameter: 10mm
-
Thread: M8 x 0.75
-
Body Length: 16mm
-
Dimensions shown in millimetres
(Refer to technical drawing for precise panel cut-out sizing.)
