The AUDAC SCP230 is a versatile and compact dual-channel power amplifier, engineered for professional audio installations where reliability, efficiency, and performance are essential. Despite its half 19” rack space design, it delivers impressive output power and flexible configuration options.
With 2 × 300 W at 4 Ω or 600 W in 70/100 V mode, the SCP230 is perfect for driving both low-impedance loudspeakers and constant voltage speaker lines, making it an excellent choice for commercial, educational, hospitality, and corporate sound systems.
Its Class-D amplifier technology ensures high efficiency and low heat dissipation, while advanced protection circuitry guarantees safe, long-term operation. The unit also features detachable connectors for quick installation and integration into fixed setups.
Key Features
-
Compact dual-channel power amplifier
-
Output: 2 × 300 W @ 4 Ω or 600 W @ 70/100 V
-
Energy-efficient Class-D technology
-
Half-rack 19” design for space-saving installation
-
Advanced protection circuits for safe, reliable use
-
Detachable connectors for fast and secure setup
-
Ideal for fixed installations in schools, offices, retail, and hospitality venues
Specifications
-
Model: SCP230
-
Amplifier type: Class-D
-
Channels: 2
-
Power output:
-
2 × 300 W @ 4 Ω
-
600 W in 70/100 V mode
-
-
Frequency response: 20 Hz – 20 kHz
-
Signal-to-noise ratio: >90 dB
-
Protections: Overload, short circuit, thermal, DC
-
Dimensions: Half 19” rack width × 1U height
-
Applications: Installed sound, commercial audio, background/foreground music systems
