CTMFX CAT Tails MFX – Two Male & Two Female XLR

CAT Tails Send Receive/Receive Send
Analog Audio Over Cat/Ethernet Breakout Snake
Simplify your smaller jobs with SoundTools modular stage snake units. SoundTools CAT Tails Send-Receive is an easy-to-use Analog-Audio-Over-Cat breakout that eliminates the need for several bulky cables. Combine with our CAT Box send/receive units to both send and receive through the same shielded ethernet cable.-Perfect for lightweight, portable set ups for DJs, weddings, or recordings.-Four 24” AES3 grade cables plug directly into analog or digital consoles.-Compatible with 48-volt phantom power when using shielded Cat5e or better cable.-Four channels available in 2 female XLR, 2 male XLR or 2 male XLR, 2 female XLR configurations with clearly laser-etched numbers to keep track of channels.

SEND AND RECEIVE ON ONE CABLE
CAT Tails Send and Receive units allow you to easily run 2 lines in and 2 lines out, over just one shielded Category 5e or better cable. Each CAT Tails send-receive unit breaks out to 2 female XLR connectors and 2 male XLR connectors. Great for smaller jobs like DJ or wedding set ups, or for quick and easy gender turnarounds.

RUGGED AND RELIABLE
All SoundTools products are guaranteed with our Happy Human Warranty to be reliable for a lifetime of active use on stages or in studios or gathering spaces. We chose the best in entertainment grade Neutrik connectors and AES3 grade cabling, and then housed the connections in ultra-rugged machined anodized aluminum.

TRAVEL FRIENDLY
SoundTools CAT Tails and our other Analog-Audio-Over-Cat products were designed for a smaller footprint and easier set up and tear down. Simplify your stage set up with SoundTools CAT Tails by running one slim shielded category 5e or better ethernet cable to replace 4 bulky XLR cables.

BUILD YOUR OWN SNAKE
CAT Tails are compatible with all of our Analog-Audio-Over-Cat line of products, including the SoundTools CAT Box, CAT Rack, and WallCAT units. Use our entertainment grade line of cable including SoundTools SuperCAT, SuperCAT Sound, or SuperCAT 7 to ensure lossless audio and com with no interference and no distortion.

DIMENSIONS

Unit
Height x Width x Depth:
1.475 in (37.465mm) x 29 in (736.6mm) x
1.475 in (37.465mm)
Weight: .6 oz (.017 KG)
In Package
Height x Width x Depth:
4.5 in (114.3mm) x 8.75 in (222.25mm) x
2.25 in (57.15mm)
Weight: 16 oz (.45 KG)

SYSTEM REQUIREMENTS

*Requires shielded cable for full functionality
Analog audio (including phantom power!)
DMX signals
AES3 compatable
Intercom

TECHNICAL SPECIFICATIONS

4 channels of balanced analog audio over Cat5
Two XLR Inputs and Two XLR Outputs
4 high qualilty AES3 cable breakouts
Compatible with DMX, COM and other 3-pin XLR based COM systems
AES72-2O compliant
Available in 2 male/2 female or 2 female/2 male configurations

DOCUMENTATION

– Wiring Diagram
– Instructions

PACKAGE CONTENTS

CAT Tail (male or female unit)
User documentation

WARRANTY INFORMATION

Lifetime Happy Human Warranty

PART NUMBER

CTMFX : 2 Male XLRs (Outputs) + 2 Female XLRs (Inputs)
CTFMX : 2 Female XLRs (Inputs) + 2 Male XLRs (Outputs)
