DB Opera 12″ Powered Speaker

The OPERA 12 from dB Technologies provides exceptional power and a unique acoustic design combine in order to deliver a vigorous yet accurate audio performance, successfully adaptable to both playback and live music applications.
With the new OPERA series, dBTechnologies succeded once again in packing leading edge DSP processing, advanced design features and user friendliness in an unrivalled cabinet in its price range. Exceptional power and a unique acoustic design combine in order to deliver a vigorous yet pristine sound, successfully adaptable to both playback and live music applications.
Opera’s asymmetrical horn has been completely redesigned in order to obtain both an asymetrical vertical dispersion and a double horizontal dispersion, ensuring an optimized throw pattern.
The system is equipped with a powerful Class D 600 W amplifier featuring advanced DSP processing where FIR filters allow the systems to deliver a coherent audio performance, uniform and crystal-clear from every listening position.
Feautres

1200 W Peak Power
600 W RMS Power
Newly Designed Asymmetrical Horn
Advanced DSP With Fir Filters
2 Input Channels (Mic-Line/Mic-Instr)
Selectable Output Channel (Link Ch1/Mix Ch 1+2)
8 EQ Presets
Fresh Full Grille Design
Stage Monitor Use

Asymmetrical Horn
The new dBTechnologies asymmetrical horn design delivers similar effective coverage for smaller applications. The high-frequency horn is narrower on top to bundle sound and throw it over greater distances. It flares out at the bottom to achieve a wider pattern of throw. (This compensates for high frequency loss as sound travels further from the source) and distributes the signal more uniformly across all audience areas.
Multifunctional Housing
A multifunctional housing offers many placement options, for instance as a floor monitor, satellite speaker in combination with subwoofers or as a fullrange system on pole mounts.
Preset System
The opportunity of modifying the character and equalization of a speaker is a very important prerogative in adapting a speaker to multiple functions. The introduction of the Preset System in dBTechnologies’ FM monitors enables to choose directly from the box the most adeguate equalization for the desired use, optimizing performances without the need of external processors. The management of phase, limiter and x-over will be modified automatically depending on the chosen set-up, preserving the internal acoustic equipment.
Specifications

Technical Data


Speaker Type
2-Way Active Speaker




Acoustical data


Frequency Response [-10dB]
52 – 20.000 Hz

Frequency Response [- 3dB]
67 – 19.600 Hz

Max SPL
129 dB

HF
1″ Exit, 1.4 v.c.

Type HF
Compression driver

Horizontal Directivity
100° (85° up/120° down)

Vertical Directivity
85° (+ 25°/-60°)

Horn
Asymmetrical Horn

LF
12″, 2″ v.c.




Amplifier


Amp Technology
Amp SMPS Power supply dual range

Amp Class
Class D

RMS Power
600 W

Peak Power
1200 W




Processor


Controller
DSP 56 bit

AD/DA Converter
24 bit/48 KHz

System Presets
Rotary Encoder (8 Presets)

CrossOver Frequency
2000 Hz

Limiter
Peak, RMS, Thermal

Advanced DSP Functions
Linear Phase FIR Filters




Input


Signal Input
1xCombo (XLR/Jack 6.3 mm) MIC/Line1xCombo (XLR/Jack 6.3 mm) MIC/Inst

Signal Output
1x XLR Male (CH1 Link/Mix OUT)Selectable




Mechanics


Housing
Polyproylene

Grille
Full grille

Handles
1 on left Side, 1 on Top

Rigging Points
2XM10 on Top + 1x M10 on Back

Pole Mount
D36 mm

Angles up
Monitor use 45°

Width
350 mm (13.78 in)

Height
642 mm (25.28 in)

Depth
349 mm (13.74 in

Weight
14.3 kg (31.53 lbs)
