dB Technologies OPERA REEVO 212 – 2×12″ Quasi 3-Way Active Speaker

The dB Technologies OPERA REEVO 212 is a portable, high-output active speaker delivering touring-grade sound definition in a versatile compact enclosure. Its quasi 3-way coaxial acoustic design – inspired by dBTechnologies’ touring series – combines two 12″ neodymium woofers with a 1″ compression driver and integrated HF horn for astonishing sound pressure and intelligibility.

Powered by a 1050W RMS Class D Digipro G2 amplifier with 28/56-bit DSP and Linear Phase FIR filters, the REEVO 212 works equally well as a wedge stage monitor, full-range PA top, or in permanent installation thanks to its 2x M10 top + 1x M10 back rigging points and standard pole mount.

Specifications

• Speaker Type: Quasi 3-Way Active Speaker
• Frequency Response (-10dB): 48 – 20,000 Hz
• Max SPL: 133 dB
• RMS Power: 1050 W (525 + 525)
• Peak Power: 2100 W
• Amplifier: Class D Digipro G2
• HF Driver: 1x 1″ compression driver, 1.75″ voice coil
• LF Drivers: 2x 12″ neodymium, 2.5″ voice coil
• Crossover Frequency: 1260 Hz
• Directivity (HxV): 100° x 80°
• Input: 1x Combo (XLR/Jack 6.3mm) line; 1x XLR Male True link out
• DSP: 28/56-bit, 24-bit/48kHz AD/DA, Linear Phase FIR
• Dimensions (WxHxD): 345 x 690 x 376 mm
• Weight: 20.4 kg
• Rigging: 2x M10 top + 1x M10 back; D36 pole mount
