E MAX 3112 12″ FULL RANGE HIGH POWER PASSIVE SPEAKER

129 DB SPL MAX   350 W AES POWER RATING   55 – 20000 HZ FREQUENCY RANGE   1” COMPRESSION DRIVER, 12” WOOFER HI RESOLUTION TRANSDUCERS The full-range passive two-way RCF E-MAX series has been specifically designed as club systems for entertainment, to achieve the best nearfield quality, vocal coherence and a stable tonal balance even at high volume. The heavy-duty speaker cabinet is made of plywood coated with black textured acrylic paint. Featuring a 12” woofer with a 2.5” voice and a 1.0” compression driver with 1.4” voice coil. The LICC crossover design includes an electronic protection on high-frequency device. The rotatable 90°x70° horn and the available mounting accessories allow installation of the loudspeaker either vertically or horizontally in any environment and architectural constraint.   DESIGNED TO PERFORM The RCF E Max series and its components are designed inside RCF’s laboratories and feature superior transducers. Equipped with a rotatable horn with 90° x 70° dispersion pattern, E MAX 3112 boasts a 12” woofer and 1” compression driver, and delivers a maximum SPL of 129 dB over a frequency range of 55 Hz – 20 kHz, with a total power handling of 350 W RMS. PERFECTLY TUNED CROSSOVER The E MAX Series features a custom designed mid-freq shaping for close distance listening on a perfectly tuned crossover to ensure the best frequency and phase response. The LICC crossover design includes electronic protection on high-frequency device. CABINET & MECHANICS All E Max Series cabinets are built in heavy-duty birch plywood coated with black textured epoxy. A sturdy black metal grille protects the front, and an acoustically transparent sound foam backing on the inside of the grille ensures protection from dust and humidity. The base of each speaker includes a robust steel pole socket for mounting on a stand or a subwoofer pole. Included are rigging points to fly the speakers for maximum architectural freedom on any installation. Threaded inserts are provided for optional mounting hardware in Installed Sound Applications. SPECIFICATIONS Acoustical specifications   FREQUENCY RESPONSE (-10DB): 55 Hz ÷ 20000 Hz   MAX SPL @ 1M: 129 dB   HORIZONTAL COVERAGE ANGLE: 90°   VERTICAL COVERAGE ANGLE: 70°   DIRECTIVITY INDEX Q: 11   SYSTEM SENSITIVITY: 98 dB Power section   NOMINAL IMPEDANCE (OHM): 8 ohm   POWER HANDLING: 350 W RMS   PEAK POWER HANDLING: 1400 W PEAK   RECOMMENDED AMPLIFIER: 700 W   PROTECTIONS: ACTIVE MOSFET   CROSSOVER FREQUENCIES: 1800 Hz Transducers   COMPRESSION DRIVER: 1.0” neo, 1.5” v.c   NOMINAL IMPEDANCE (OHM): 8 ohm   INPUT POWER RATING: 50 W AES, 100 W PEAK   SENSITIVITY (DB, 1W @ 1M): 106 dB, 1W @ 1m   WOOFER: 12”, 2.5” v.c   NOMINAL IMPEDANCE (OHM): 8 ohm   INPUT POWER RATING: 300 W AES, 600 W PEAK   SENSITIVITY (DB, 1W @ 1M): 98 dB, 1W @ 1m Input/Output section   INPUT CONNECTORS: Speakon® NL4   OUTPUT CONNECTORS: Speakon® NL4 Standard compliance   CE MARKING: Yes Physical specifications   CABINET/CASE MATERIAL: Plywood   HARDWARE: 17 x M10 2 x M8   HANDLES: 1 Top   POLE MOUNT/CAP: Yes   GRILLE: Steel   COLOR: Black Size   HEIGHT: 614 mm / 24.17 inches   WIDTH: 381 mm / 15 inches   DEPTH: 422 mm / 16.61 inches   WEIGHT: 22 kg / 48.5 lbs Shipping informations   PACKAGE HEIGHT: 684 mm / 26.93 inches   PACKAGE WIDTH: 449 mm / 17.68 inches   PACKAGE DEPTH: 493 mm / 19.41 inches   PACKAGE WEIGHT: 26 kg / 57.32 lbs
