JBL SRX835P 15″ Three-Way Powered Speaker System

$4,099.00 $3,749.00 Inc GST

or from $2,249.00 today & 5 weekly interest-free payments of $300.00 with Laybuy

-9%
Sale!

JBL SRX835P 15″ Three-Way Powered Speaker System

$4,099.00 $3,749.00 Inc GST

or from $2,249.00 today & 5 weekly interest-free payments of $300.00 with Laybuy

-9%
Or 10 Interest free payments from $374.90 Genoapay logo What's this?

.

Can Order From Suppler Delivery Times Vary as some shipments are Delayed - Contact For ETA

or from $2,249.00 today & 5 weekly interest-free payments of $300.00 with Laybuy what's this?

SKU: SRX835P Category: Tags: , Product Brand:

Free NZ shipping on all orders over $499 (Select at Checkout)

  • $9 Flat Rate Shipping (For Orders Under $499)
  • Order Before 12pm to get Dispatched Same Day (Hamilton Stock Only)

Description

The JBL SRX835P 15″ Three-Way Powered Speaker System is the next generation high performance powered loudspeaker system comprising three full range and two subwoofer models with an array of features that elevate the SRX800 Series to the best in class of all competitive systems. The full range 381mm three-way, SRX835P features legendary JBL Drivers, proprietary 2,000 Watt Crown amplification, Crown Front-End DriveCore Technology, premium JBL user-configurable DSP, V5 Tunings compatible with Vertec and VTX touring systems, and HiQnet Network control options via iOS and Android applications. Drawing on JBL’s long history of groundbreaking technology and loudspeaker design, the SRX800 Series meets the needs of touring houses, installations, and the most demanding live sound applications ensuring they can deploy a no-compromise, all-in-one solution featuring legendary JBL sound and performance, a wide array of configurability, and compatibility with JBL’s flagship touring systems.

Purposeful Design
Every detail in the SRX800 Series was purposefully designed and thought through with full consideration for its intended use, each component carefully matched to achieve a perfectly tuned system that is powerful, easy to use, reliable and extremely rugged. Ergonomically designed handles support an easy, non-fatiguing grip for streamlined handling. M10 suspension points, indexed feet, and pole/tripod mounts support a wide, flexible array of configurations. An LCD screen and glow in the dark back-panel ink ensure fast, accurate setup even in low light.

Transducer Technology
JBL’s patented Differential Drive Technology ferrite drivers incorporate 76.2mm voice coils with lower mass ferrite magnets for reduced weight, increased power handling, exceptionally low distortion and extended low frequency response. JBL’s 2432H is the only neodymium 76.2mm voice coil compression driver in this class, delivering very high power levels and smooth, crystal clear sound. A JBL patented midrange section incorporates the heat sink, acoustic cavity and structural support into one piece.

DriveCore BY
Each model is Powered By Crown Proprietary Front-End DriveCore Technology featuring a massive 2000W Power Rating, the highest power rating in this class of loudspeakers. With an outstandingly low 103dB signalto-noise ratio, the SRX800 Series is capable of massive sound pressure levels with exceptional headroom, very low distortion and absolute clarity throughout its frequency range. True Universal PS w/ PFC and locking IEC power cords ensure quick and secure connection for easy setups.

Control
A full suite of User Controllable DSP driven by the SRX800 Series powerful onboard 400mHz Sharc DSP includes 20 PEQ’s, 2 seconds of delay, signal generators, Input mixing, amplifier monitoring, and 50 User Presets. In addition, the system can incorporate V5 JBL Tunings providing compatibility with our flagship Vertec and VTX touring systems. An integrated LCD screen supports fast setup and configuration.

Key Features

  • Purposeful Design: Rugged, Intuitive to Use, Easy to Transport
  • JBL Premium Transducers
  • Drivecore Amplification By Crown
  • Full User Configurable DSP
  • Network Control
  • JBL Engineered Application Presets
  • LCD Screen and Glow in the Dark Ink on Back Panel
  • M10 Suspension Points
  • Standard 35mm Pole Cup

Specifications

Connectors 2x Neutrik ¼ – XLR combo input
2x Neutrik XLR-3M Output
1 x XLR-3M mix output
SPL 137 dB
Max SPL Level 137 dB
Frequency Response 41 to 20,000 Hz (-3 dB)
Coverage 60° x 40°
Amplifier Class D
Power Rating 2000 W peak, 1500 W continuous
Input Impedance 40 kilOhm balanced
20 kilOhm unbalanced
Maximum Line Input Gain 21 dB
Gain Line input:21 dB
Consumer input: 3 dB
Mic input: 45 dBLine input: 20 dBu
Consumer input: 8 dBu
Mic input: -4 dBu
LED Indicators Power LED: green
Network Link: green
Network Data: yellow
Cooling On demand variable speed fan
AC Power 100 to 240 V at 50/60 Hz
Power Consumption 120 V: 2.2 A (1/8th power), 5.6 A (1/3rd power)
Handles 2
Crossover 330 and 2,400 Hz
Material 18 mm plywood
Finish Obsidian Duraflex finish
Grille Powder coated, Onsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
Mounting Single 36 mm pole socket
12x M10 suspension points
Dimensions (L x W x H) 98.40 x 54.40 x 47.60 cm
Weight 38.6 kg

Brand

JBL
