Flexible. Powerful. Professional.

The Kiloview E3 is a next-generation dual-channel video encoder designed for professional broadcast, live streaming, corporate AV, education, house-of-worship, and remote production environments.

With 4K HDMI input, 3G-SDI input, USB video input, full HEVC (H.265) / H.264 encoding, PoE support, multi-protocol streaming, PTZ control, intercom integration, and simultaneous recording — the E3 is one of the most versatile compact encoders available today.

---

🎥 Triple Input Flexibility

HDMI Input (HDMI 1.4b)

Supports:

• 3840×2160p30 (4K)

• 1080p up to 60fps

• 1080i

• 720p

• PAL / NTSC SD formats

3G-SDI Input

Supports:

• 1080p up to 60fps

• 1080i

• 720p

• PAL / NTSC SD formats

USB Video Input (UVC)

Supports:

• 1080p up to 60fps

• 720p

Both HDMI and SDI offer loop-out for monitoring.

---

🔄 Simultaneous & Mixed Encoding

The E3 allows you to:

• Encode HDMI only

• Encode SDI only

• Encode both inputs simultaneously (up to 1080p60)

• Mix HDMI + SDI into one output (PIP or PBP layout)

If HDMI is set to 4Kp30, output can be downscaled to 1080p for simultaneous encoding.

---

⚡ Advanced Video Encoding

Supported codecs:

• H.265 (HEVC) – up to 50% bandwidth savings

• H.264 (AVC)

• M-JPEG

Maximum bitrate: Up to 100 Mbps

Supports interlaced input but outputs progressive streaming.

---

🌐 Full Multi-Protocol Streaming

Compatible with virtually all IP production environments:

• NDI®|HX2 / HX3

• SRT

• RTMP / RTMPS

• WHIP

• HLS

• TS over UDP

• RTSP

• ONVIF

Perfect for:

• NDI production workflows

• Remote production via SRT

• Live streaming to CDN platforms

• Broadcast contribution feeds

---

🚀 Stream to 16 Destinations at Once

The Kiloview E3 supports:

• 8 Main Streams (up to 1080p)

• 8 Sub Streams (up to 720p)

• Adjustable bitrate per stream

• Simultaneous multi-platform delivery

Ideal for redundant streaming, multi-CDN distribution, and content syndication.

---

🎬 Professional Video Processing

Pre-encoding processing includes:

• Rotation

• Mirroring

• Cropping

• Custom image overlays

• Text / OSD insertion

• SEI Timecode (NTP or system sync)

• SDI REC-RUN camera start/stop synchronisation

The built-in 1.14″ LCD colour display provides:

• IP address

• CPU & memory status

• Resolution

• Temperature

• Tally indication (Preview / Program)

---

🎵 Advanced Audio Capabilities

Audio Inputs:

• 4-channel SDI embedded audio

• 4-channel HDMI embedded audio

• 4-channel USB embedded audio

• 3.5mm Line In (2-channel)

Audio Encoding Formats:

• AAC

• G.711

• MP2

• MP3

Additional features:

• Audio de-embedding

• Channel selection & mapping

• Alternate channel switching

---

🎧 Intercom & PTZ Control

Voice Intercom

• Supports USB headsets

• Works with Kiloview Intercom System (KIS)

PTZ Control

• USB-to-Serial (RS-232 / RS-485 / RS-422)

• Sony VISCA

• Pelco-D / Pelco-P

• UVC PTZ compatibility

Ideal for integrated camera control in live production setups.

---

💾 Recording + Streaming Simultaneously

Record directly to:

• External USB storage

• NAS storage

Recording formats:

• MP4

• MOV

• TS

Perfect for backup recording, post-production, or compliance archiving.

---

🔌 Connectivity & Power

• 1 × Gigabit Ethernet (1000Mbps)

• PoE supported

• DC 12V / 1A power input

• Power consumption: <6W

USB Ports:

• 2 × USB 2.0 Type-C (Front)

• 1 × USB 2.0 Type-A (Rear)

Mounting:

• Cold shoe mount

• Compact size: 140 × 100 × 28mm

• Weight: 400g

Operating temperature:

• -20°C to 45°C

---

✅ Ideal Applications

• Live event streaming

• Corporate AV systems

• Sports broadcasting

• Education lecture capture

• House of worship

• Remote production workflows

• NDI studio environments

• Multi-platform streaming setups

---

📦 What’s Included

• Kiloview E3 Encoder

• Power supply

• Quick start guide

---

Why Choose the Kiloview E3?

✔ Dual HDMI + SDI + USB input
✔ HEVC for bandwidth efficiency
✔ 16 simultaneous stream outputs
✔ Full professional protocol support
✔ PoE powered
✔ PTZ & intercom integration
✔ Compact, low power, broadcast-ready design

The Kiloview E3 delivers professional-grade encoding performance in a compact, highly flexible unit built for modern IP video production workflows.
