LD Dual 8″ Powered Subwoofer

The SUB88A features a 150 Watt (RMS) Mono-amplification unit offering great sound and dynamic characteristics. It is a perfect partner for the SAT62A active speaker or for the passive models SAT42/242/62 in combination with an external amplification unit such as the DJ200.
It can naturally be used with any other high/medium speaker if you wish to complete your sound with a deep and powerful bass fundament.
Specifications

General

Product type
PA subwoofer

Type
Powered

Low/mid Woofer dimensions
2 x 8 ”

Woofer dimensions (mm)
2 x 203 mm

Woofer magnet
Ferrite

Woofer brand
Custom-made

Amplifier
Class A/B

System Power (RMS)
150 W

Frequency response
40 – 120

SPL (1W/1m)
92 dB

Max. SPL
115 dB

Protection circuits
overload

Controls
Low-pass filter (70 – 140 Hz), Phase 180°, volume

Indicators
Limit, Power, Signal

Line inputs
1

Line input connectors
6.3 mm jack, XLR

Power supply
transformer

Operating voltage
220 V AC – 240 V AC, 50-60 Hz

Cabinet material
15 mm MDF

Cabinet surface
texture paint

Cabinet colour
Black

Cabinet construction
Bandpass

Width
600 mm

Height
250 mm

Depth
350 mm

Weight
15 kg
