Locking male cable connector, screw terminals
The powerCON TRUE1 TOP is a locking 16 A true mains connector for outdoor applications. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection.
The powerCON TRUE1 TOP is a connector with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live.
Features & Benefits
Heavy duty sealed power connector for harsh and demanding environment
IP65 rating and certified outdoor protection to UL 50E enclosure type 4 (in mated condition)
Uses high impact UV-resistant materials
True mains connector with breaking capacity (CBC)
Lockable 16 A single phase connector (USA: 20 A)
Easy and reliable twist lock system
Extremely robust and reliable
Unique Neutrik cable retention
ENEC certified according to IEC 60320
UL498 certified
Technical Information
Product
Title
NAC3MX-W-TOP
Electrical
Contact resistance
≤ 3 mΩ
Dielectric strength
4 kVdc / 2.8 kVac
Insulation resistance
0,1 GΩ (after damp heat test IEC 68-2-30)
Number of electronical contacts
2 + PE
Rated current per contact
16 A rms (USA: 20 A)
Rated voltage
250 V ac
Mechanical
Cable O.D.
6 – 12 mm
Lifetime
> 5000 mating cycles
Wiresize
1.0 – 2.5 mm²
Wiresize
12 AWG
Material
Contact plating
2 µm Ag
Contacts
CuNi1Si0.2
Insert
Polyamide (PA 6.6 30 % GR)
Locking element
ZuAl4Cu1
Shell
Polyamide (PA 6.6 30 % GR)
Strain relief
Polyacetal (POM)
Environmental
Flammability
UL 94 V-0
Protection class
IP65, UL50E enclosure type 4 (mated)
Temperature range
-30 °C – +80 °C
