Features
Bluetooth® Wireless Technology
Music data from a compatible device is sent to the main unit by wireless transmission. So you can enjoy the music from smartphone or tablet with your home theater system in high quality sound.
*The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license.
Specs
Black
Silver
Size and Weight
Height
123mm
Width
184mm
Depth
228mm
Weight
1.1kg
The size of the speaker is H224 x W139 x D136 mm and its weight is approximately 1.3 kg.
Stream your music wirelessly
Rich bass & clear sound
Low power consumption
Auto off & 0.2W at standby mode
CLOSE ALL SPECS
Color
Silver / Black
Audio System
Output Channel
2ch
Output Power
Front Channel (both ch driven)
10W per channel (6ohms, 1kHz, 10% THD)
Total RMS power
20W
Speaker System
Type
1 way, 1 speaker system (Bass reflex)
Speaker Unit
Full range 10cm Cone type x 1Bass Reflex Port
CD / DVD
Playback Disc *¹
CD-R / RW
Format
CD-DA / MP3
USB
USB Standard
USB 2.0 full speed
Support Format
MP3
Play / Rec.
Play *²
Battery Charge
500mA
Radio
Station Presets
FM
30 stations
DAB Plus
–
Antenna Terminal
75ohm
RDS
–
Network
Bluetooth
Version
Bluetooth® Ver 2.1 + EDR
Class
Class 2
Wi-Fi
–
NFC
–
Smartphone App
Panasonic Music Streaming*³
Yes (iOS / Android)
Sound Function
Super Sound EQ, Super Bass Sound
D.Bass
Preset EQ
Normal Preset EQ
Manual EQ
Bass / Treble
Surround
Y
My sound setting
–
Re-Master
Bluetooth Re-Master
Low Distortion Technology
–
Karaoke
–
Terminals
USB Port
x1
Audio IN
–
Audio OUT
–
Mic Jack
–
LAN
–
General
Power Supply
AC220-240V, 50Hz
Power Consumption
Normal Use
14W
Normal Standby
0.2W
BT Standby
0.3W
Auto Power OFF
Y
Dimmer
Y
Timer Function
Sleep
Y
Clock
Y
Play Timer
Y
Rec Timer
–
Dimensions, Weight
Main Unit
Dimensions (W x H x D)
184 x 123 x 228 mm
Weight
1.1 Kg
Speaker Unit
Dimensions (W x H x D)
139 x 224 x 136 mm
Weight
1.3 Kg
Note
*1 Playability may vary depending on the contents, discs and quality of the recording.*2 Only a USB flash drive. Playback is not possible from a portable device (Apple, Android, etc.) using a USB extension cable.*3 Download on the App Store. Download on Google Play™.*4 Specifications are subject to change without notice. All numbers given here are approximate.LEGAL NOTICE:Recording and playback of content on this (or any other) device may require permission from the copyright owner. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright law in your country.TRADEMARK NOTICE:Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.Google Play is a trademark of Google Inc.The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners.The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. Used with permission. AllPlay is a trademark of Qualcomm Connected Experiences, Inc., registered in the United States and other counties. Used with permission.
