The Temblor T10 Active 10″ Studio Subwoofer is designed for low frequency sound reinforcement while monitoring in a recording studio. The subwoofer utilises a 10-inch composite low frequency driver with a frequency response of 20 to 200 Hz and a maximum SPL of 110 dB. The driver is housed within a heavily braced and reinforced MDF cabinet with a vinyl finish and ported bass reflex design. It is powered by a 250 Watt Class AB plate amplifier. To reduce vibration, the unit features internal dampening and rests on built-in feet. The subwoofer features a variable crossover frequency between 50 and 130 Hz, input gain controls from -30 dB to +6 dB, a 0° or 180° phase switch, and a ground lift switch.
You can connect to the subwoofer via a pair of balanced XLR inputs, a balanced pair of 1/4″ TRS inputs, or an unbalanced pair of RCA inputs. The subwoofer also includes a balanced pair of XLR pass-through outputs, a balanced pair of 1/4″ TRS pass-through outputs, and a balanced XLR sub output. The unit features a 120/240 VAC switchable power supply to accompany studio monitors in different regions.
Specifications
| Transducer | 10″ Composite |
| Power | 250 W |
| Amplifier Type | Class AB |
| Maximum SPL | 110 dB continuous |
| Controls | Input gain: continuously variable from -30 to +6 dB Low pass filter: continuously variable from 50 to 130 Hz Phase switch: 0° and 180° Ground lift switch |
| Inputs | Left and right balanced XLR Left and right balanced 1/4″ TRS Left and right unbalanced RCA |
| Outputs | Left and right balanced XLR pass-through Left and right balanced 1/4″ TRS pass-through Balanced XLR Sub out 1/4″ Sub bypass |
| Design | Front firing bass-reflex acoustic port Internal dampening and heat sink |
| Construction | Resonance-suppressing internal bracing Internal dampening and heat sink |
| Frequency Response | 20 to 200 Hz |
| Crossover Frequency | Variable 50 to 130 Hz |
| Voltage | 100 to 120 VAC at 50/60 Hz 220 to 240 VAC at 50-60 Hz |
| Dimensions (H x W x D) | 410 x 335 x 406 mm |
| Weight | 14.4 kg |
