Description
The Shure SLXD5 Digital Camera-Mount Wireless Microphone Receiver is an ideal solution for videographers, journalists, documentary makers, and content producers looking for a high-quality camera-mount digital wireless microphone receiver. Its user-friendly setup makes it effortless to use, even when utilizing multiple systems on set. Compatible with the SLXD1 bodypack, SLXD2 handheld, and SLXD3 plug-on transmitters, this single-channel receiver is incredibly versatile. It conveniently includes a cold-shoe mount for seamless camera integration and is compact enough to fit effortlessly into an audio bag. With its wide range of features, the SLXD5 ensures reliable wireless transmission and professional-grade audio results, which are essential for demanding filmmakers and creators.
Specifications
| Key Specs | |
| Wireless Technology | Digital UHF |
| Diversity | True Digital Diversity |
| Max Operating Range | 328′ / 100 m |
| Receiver Type | Camera-Mount |
| Number of Audio Channels | 1 |
| Audio I/O | 1 x 1/8″ / 3.5 mm TRS Female Balanced Mic/Line Output 1 x 1/8″ / 3.5 mm TRS Female Unbalanced Headphone Output |
| Network I/O | No |
| Power Requirements | Battery, Bus Power (USB) |
| Number of RF Channel Frequencies | 1760 |
| Diversity | True Digital Diversity |
| RF Frequency Band | L57: 650- 693 MHz |
| RF Bandwidth | 43 MHz |
| Frequency Step Size | 25 kHz |
| RF Channel Scanning | Auto-Scan |
| Max Operating Range | 328′ / 100 m |
| Max Transmitters per Band | 32 |
| Timecode Support | Yes |
| Mobile App Compatible | No |
| Latency | 3.2 ms |
| THD | <0.02 % |
| Receiver | |
| Receiver Type | Camera-Mount |
| Mounting Options | Shoe-Mount (with Included Hardware) |
| Antenna | 2 x 1/4 Wave Flexible Whip, Fixed (Front-Mount) |
| Number of Audio Channels | 1 |
| Audio I/O | 1 x 1/8″ / 3.5 mm TRS Female Balanced Mic/Line Output 1 x 1/8″ / 3.5 mm TRS Female Unbalanced Headphone Output |
| Gain Range | -18 to +42 dB |
| Audio Output Level | 1/8″ / 3.5 mm Output: +15 dB (Line Level, Balanced) |
| Phantom Power Protection | No |
| Frequency Response | 20 Hz to 20 kHz +1/-2 dB (Dependant on Mic) |
| Network I/O | No |
| USB/Lightning Connectivity | 1 x USB-C Female (Bus Power, Charging) |
| USB Class-Compliant | No, USB Charging/Power Only |
| Standalone Audio Interface Capable | No |
| Impedance | 1/8″ / 3.5 mm Output: 450 Ohms (Balanced) |
| Approximate RF Sensitivity | -97 dBm |
| Spurious | Rejection: >75 dB |
| Power Requirements | Battery, Bus Power (USB) |
| Battery Type | 2 x AA 1 x Shure SB903 |
| Approx. Battery Life | 5.5 Hours |
| Display & Indicators | OLED (AF Level, Battery Status, Channel, Frequency, Group, Menu Navigation, Metering, Multifunction, Output Level, RF Level, Sync, Transmitter Battery Status) |
| Housing | Aluminium |
| Operating Temperature | 0 to 122°F / -17 to 50°C |
| Storage Temperature | -20 to 165°F / -28 to 73°C |
| Dimensions | 2.7 x 4.2 x 1″ / 68 x 107 x 25.3 mm |
| Weight | 0.4 lb / 182 g |
