TAO 1pro-S is a NDI encoder/ decoder with a 5.5 inch FHD preview display, which also comes with 1 profession-scale SDI input, 1 HDMI 1.3 input and 2 USB 3.0 inputs.TAO 1pro-S is compatible with standard USB 2.0 and USB 3.0 cameras by UVC protocol.With a touch panel for finger configuration, TAO 1pro-S is with optional 2 chargeable battery extending its capacity for outdoor application.
NDI encoder and decoder
5.5 inch HD touch screen for operation
Asynchronous rotation of main screen and HDMI output
2*UVC inputs,1*HDMI 1.3 input,1*SDI input and 1*HDMI 2.0 output
HDCP supported
Sound column
Type-C interface for charging, support PD protocol
Compatible with SONY NF970 and Panasonic AG-VBR59MC, standard battery socket (no battery install for standard version)
Connectors
Input
HDMI 1.3
1×HDMI-A
SDI
1xBNC
USB 3.0
2×USB-A
Output
HDMI 2.0
1×HDMI-A
Record
USB 2.0
1×USB-A
Audio
In
1×3.5mm Audio Jack
Out
1×3.5mm Audio Jack
Communication
LAN
1×RJ45
Power
1×USB-C
Performance
Input Resolutions
HDMI
SMPTE
720p@50/60 | 1080p@23/24/60
VESA
1024×768@60 | 1280×720@60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 |
1600×1200@60 | 1680×1050@60 | 1920×1080@60
Output Resolutions
HDMI
SMPTE
720p@50/60 | 1080p@24/25/50/60 | 2160p@60
VESA
1024×768@60 | 1280×720@50/60 | 1280×800@60 | 1280×1024@60 | 1360×768@60 |
1920×1080@50/60 | 3840×2160@60
Supported Standard
HDMI
1.3(Input) | 2.0(Output)
USB
3.0
Screen Feature
Screen Dimension
5.5 ’’TFT
Resolution
1080×1920 pixels
Dot Pitch
0.063(H)×0.021(W)(mm)
Aspect Ratio
16:9
Brightness
450cd/m²
Contrast
1000:1
Backlight
LED
View Angle
80°/80°(L/R)80°/80°(U/D)
Power
Input Voltage
9V/2A
Max Power
18W
Environment
Temperature
0℃~55℃
Humidity
5%~85%
Physical
Weight
Net
350g(without battery);882g(with battery)
Package
770g
Dimension
Net
161mm×106mm×36mm
Package
255mm×145mm×85mm
*1. i signal input and output are not supported;
*2. Reboot is required for signal format modification;
*3. Delay of decoding and encoding is affected by the network.
