A feature-mix boosting high-end audio performance as well as advanced versatility. As a matter of facts, VIO X cabinets serve impressively as a stand alone PA system that can be stacked, flown or wall-mounted, as a full range PA or in combination with VIO S118 and VIO 118R subwoofers, but also act as the perfect side-fill, delay or stage monitoring system in larger VIO sound reinforcement applications.
The robust wooden enclosure allows horizontal use for monitoring purposes and is provided with a 36mm pole mount, and rigging points facilitating fixed installations with dedicated vertical and horizontal brackets.
All VIO X cabinets are powered by on board Digipro G3 900 W RMS providing majestic sound pressure levels in compact size and very limited weight. Advanced sound processing featuring Linear Phase FIR Filters allows VIO Xs to deliver an extremely coherent audio performance, standing out for its intelligibility and clarity from every listening position.
On board presets let users adapt High Pass Filters to the chosen application, as well as dedicated EQ presets for Wedge or Fullrange mode. Last but not least, VIO X is equipped with RDNet port allowing monitoring and full remote control in real time via Aurora Net software (Windows and Mac).
Technical Data
- Speaker Type 2 Way Active Loudspeaker
Acoustical data - Frequency Response [-10dB] 62 – 22.000 Hz
- Frequency Response [-6dB] 79 – 21.000 Hz
- Max SPL 132 dB
- HF 1 x1.4”, 2.5″ Neodymium
- LF 1x 12”, 3″ Neodymium
- Directivity 60° x 40° Horn Rotatable Horn
Amplifier - Amplifier 900 W RMS Class-D Digipro® G3
- Cooling Class-D Convection
- Power Supply Auto-range SMPS
Processor Controller DSP 28/56 bit - AD/DA Converter 24 bit/48 kHz
- Limiter Peak, RMS, Thermal
- Processing FIR Linear Phase Filters
Input - Signal Input 1 x XLR balanced, 1 x RJ45 Link (RDNet)
- Signal Output 1x XLR balanced, 1 x RJ45 Link (RDNet)
- Power Socket 1x PowerCON TRUE1 In 1x PowerCON TRUE1 Out
Controles - 1x Rotary Encoder (8x EQ, HPF presets)
- 1x Input sensitivity potentiometer
- 1x Mic / line switch
Special Features - Opto-isolated floating pre-amp
Mechanics - Housing Wooden Cabinet, Polyurea painting
- Handles 1x (top), 2x (side)
- Wedge Angle Monitor Use 50°
Rigging points - 12x M10 Thread + 4x Fast lock pins
- Pole Mount Ø36 mm
- Width 340 mm
- Height 650 mm
- Depth 445 mm
- Weight 20.7 kg
