Features:
- All-in-One Solution: Transmits uncompressed 18G 4K video, high-quality eARC, optical & stereo analogue audio, USB 2.0, Gigabit Ethernet and IR & RS232 control signals over a single cable.
- Extended Range: Supports connectivity up to 100 meters over Cat6A cable using HDBaseT 3.0 technology.
- Audio Versatility: Compatible with high-definition audio formats such as Dolby Atmos, DTS, Dolby Digital, LPCM and HDMI eARC/ARC.
- Bi-Directional Control: Send and receive IR, RS232 and USB signals to control connected devices from either side of the setup.
- High-Performance Video Support: Supports 18Gbps data rate for resolutions up to 4K60Hz (YUV4:4:4) with HDR, including Dolby Vision®.
- USB 2.0: Host/Client selectable from either TX or RX for connecting USB 2.0 devices in either direction.
- Power Over HDBaseT (PoH): Allows power transmission through Cat6A, so only one side needs a power source, reducing setup complexity.
Specifications:
| Video Resolution | Up to 4K60Hz (YUV4:4:4), 4K30Hz, 1080p120Hz, and 1080p3D. |
| Audio Formats | Dolby Atmos, DTS, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, and more. |
| Inputs | HDMI (TX), Stereo 3.5mm (TX), Optical audio (RX), 2 x USB A (2.0). |
| Outputs | 1 xHDMI (RX), 1 x HDMI (Mirror) – TX, USB B (2.0), Stereo 3.5mm (RX), Optical audio (TX). |
| Power Supply | DC 24V/1A (US/EU standards, CE/FCC/UL certified). |
| Operating Temperature | 32°F to 104°F (0°C to 40°C). |
| Dimensions | 73.5mm (W) x 60.7mm (D) x 17mm (H) / 2.9″ x 2.4″ x 0.7″. |
| Weight | 122g / 4.3 oz. |
