8″ DB Tech B. Hype Powered Speaker

$659.00 Inc GST

.

(1 customer review)

Stock on Order or Currently Unavailable Contact for ETA

Notify me when the item is back in stock.

Free NZ shipping on all orders over $499 (Select at Checkout)

  • $9 Flat Rate Shipping (For Orders Under $499)
  • Order Before 12pm to get Dispatched Same Day (Hamilton Stock Only) Excludes Weekends and Holidays
    *If Only 1 item is Left in stock this may have been opened for display
    *Image is for illustrative purposes only. Please refer to product description.

B·H series aims to provide a professional yet efficient sonic performance to all kind of users, combining an extremely efficient CLASS D amplifier with aggressive sound pressure levels (up to 120 dB for this 8” cabinet), while delivering the most accurate sound reproduction.

The new B-HYPE 8 is a versatile active speaker. It is equipped with one 1” compression driver (1” voice coil), and one 8” woofer (1.5” voice coil). The dispersion pattern is asymmetrical on vertical axis, and it is diversified (top and bottom) on the horizontal one. This allows a narrower and more efficient sound coverage, and a better performance in case of reverberant environments. The combo input (with source type selection) allows an easy and versatile use, suitable for a dynamic microphone and standard line input. The user can enhance lower and upper frequencies with the convenient DSP preset function. A balanced link output allows the audio connection to a second loudspeaker.

This featherweight cabinet (14 lbs/6.6 kg) come with a clean and contemporary full grille design, enhancing both portability (3 handles -1xside and 1 on top-) and multifuncionality: each cabinet can be used horizontally as a stage monitor (on both sides) and features a pole mount cup in order to be used on tripods or stacked on dBTechnologies Subs.



Technical Data
Speaker Type
2-Way Active Speaker
Acoustical data
Usable Bandwidth [-10dB]
65 – 20.000 Hz
Frequency Response [-6 dB]
70 – 19.600 Hz
Max SPL
120 dB
Type HF
Compression Driver
HF voice coil
1 “
LF
8 “
LF voice coil
1.5 “
Crossover Frequency
2300 Hz (24 dB/oct.)
Horizontal Dispersion
asymmetrical 85° up / 120°down
Vertical Dispersion
85° (+25/ -60°)
Amplifier
Amp Technology
Custom Made
Amp Class
Class D – Passice cooling (convection)
Power Peak
260 W
Processor
Controller
DSP 28/56 bit- 48 kHz
Limiter
Peak, RMS, Thermal
Controls
Volume, Audio Input Sensitivity, DSP Preset
Input
Main Connection
VDE
Signal Input
Balanced 1xCombo IN (MIC/LINE)
SIGNAL Out
(Balanced) 1xXLR OUT (LINK)
Mechanics
Housing
Polypropylene
Grille
Full Metal Grille
Handles
3 (2 on side 1 on top)
Pole Mount
36 mm
Width
243 mm (9.57 in)
Height
443mm (17.44 in)
Depth
231 mm (9.09 in)
Weight
6.6 kg (14.55 lbs)
Angles Up
Double wedge angle 45°

Additional information

Weight 5 kg

Brand

DB Techologies
