8″ Premium Ceiling Speaker White

The Tessen TNi-C8 delivers premium audio reinforcement. designed with the installer in mind, The TNi-C8 – 8 inch coaxial ceiling speaker – features a 6 position power tap selector located under the front steel grille, providing swift output adjustment once installed. With connectivity for 70V/100V and 8 ohm low impedance lines, the TNi-C8 delivers a highly flexible solution. The spring connection terminals ensure cables are secure once fitted.
Features

100V Power Options
40W, 20W, 10W

70V Power Options
20W, 10W, 5W

Frequency Response (-10)
65Hz > 20kHz

Frequency Response (-3)
80Hz – 16KHz

LF Driver
8 Inch, Paper Cone

HF Driver
1.5 INCH NEODYMIUM

Low Nominal System Impedance
8 OHM

Power
65W AES, 260W Peak

Max SPL (1M) (Peak)
115 dB SPL

Sensitivity (1W/1M)
91 dB SPL

Nominal Coverage
100° conical

Input Connector
PUSH SPRING CONNECTORS

Mounting Points
4X DOG EAR BRACKETS

Mounting Depth
195MM, (7.7″)

Installation Grip Range
4 – 20MM

Cutout
275MM, (10.8″)

Outside Diameter
300MM, (11.8″)

Unit Weight
2.6KG, 5.7 LBS

Main Construction Material
ABS PLASTIC

Grille
1.5MM CIRCULAR MESH STEEL

Finish
WHITE
