Dante AVIO Analog Input Adapter 1×0

The Audinate Dante AVIO 1-Channel Analogue Input Adapter allows you to use the analogue gear you already own with your Dante audio network. It provides audio engineers with a cost-effective solution for adapting analogue mixers, DI boxes, keyboard instruments, or analogue compressors and equalisers, delivering the interoperability, performance, and scalability of Dante network connectivity.
Compact and built for the road, the AVIO is automatically discovered by the network and is ready to use when connected. It features one balanced line-level input equipped with an XLR connector and delivers high-quality audio at up to 24-bit/96 kHz with configurable gain and attenuation, low total harmonic distortion, and a 20 Hz to 20 kHz frequency response.
The AVIO supports Dante audio over IP and AES67 RTP transport formats, and is compatible with Dante Domain Manager (DDM).
Key Features:

Cost-effective solution for adapting analogue gear to your Dante network
Plug-and-play operation
Balanced, line-level single-channel analogue input adapter
Compact and built for the road with sonically welded polycarbonate enclosure
Sample rates up to 96 kHz
Wide dynamic range
High signal-to-noise ratio
Low total harmonic distortion
Configurable gain and attenuation
Dante Audio over IP and AES67 RTP transport formats
Power over Ethernet (PoE) support
Compatible with Dante Domain Manager (DDM)

Applications

Connect analogue mixers and consoles to a Dante network
Patch DSPs, analogue compressors and equalisers into a Dante system using a combination of Dante AVIO Input and Output adapters
Connect stage DI boxes and keyboard instruments directly to a Dante network
Connect wireless mic receiver to a Dante network

Specifications

Maximum Signal Level
+24 dBu, +4 dBu, 0 dBu (balanced)0 dBV, -10 dBV (balanced)

Frequency Response
20 Hz to 20 kHz (±0.5 dB)

Impedance
20 kOhms (balanced)10 kOhms (unbalanced)

Dynamic Range
>100 dB

Signal-to-Noise Ratio
>100 dB

Total Harmonic Distortion


Connectors
RJ451 x XLR-F

Power
Class 1 802.3af PoE

Sample Rates
44.1, 48, 96 kHz

Bit Depth
24-bit

Network Transport Protocol
Dante Audio over IPAES67 RTP
