Audio Extender – 100/300 meters, Analogue/Digital Support

We all know and love the XTND range of HDBT video extenders, and it’s great to see there’s now a solution for those tricky audio feeds.

Now you can extend digital and analog audio signals up to 300m over a single CAT5e / CAT6 cable. Typical use cases could include:

• Audio to a local amplifier from a centrally-installed device
• TV audio from a room back to the head-end for reliable playback of Smart TV content through an audio distribution system or centrally-installed AVR (i.e. ARC without the hassle)

Some of the great features include:

• Built-in DAC in the RX. The Optical IN at the TX can be extracted from the Analog OUT of the the RX (heads up – no downmixing).

• Bi-directional Power over Cable (PoC) so you can power either the transmitter or receiver

• 100m @ 192KHz

• 150m @ 96KHz

• 300m @ 48KHz

• Supports a range of digital audio formats, including: PCM 2.0, LPCM, DTS, Dolby Digital, Dolby Digital Plus

• Sample rate support: 32KHz, 44.1KHz, 48KHz, 96KHz, 176.4KHz, 192KHz @ 24-bit

• Ultra-low jitter

• Plug-and-Play design

Specifications
