Description
The Audio-Technica ATR2x-USB 3.5mm to USB 2.0 Type-C Audio Adapter is designed to turn any headphone, microphone, or headset with a 3.5mm plug into a USB-compatible device. This adapter is equipped with a 3.5mm microphone input and a 3.5mm headphone output, a mute button, a volume control, and LED’s showing power and mute status. It features USB 2.0 operation and provides plug-in power for microphones that need power. A USB Type-C to USB-Type A adapter is also included for greater compatibility.
Key Features:
- The adapter features a 3.5mm headphone jack for connecting your headphones to the device. It also has a 3.5mm microphone jack to connect a standard microphone for quality recording or communication.
- With the USB 2.0 interface, the adapter provides high-speed operation with a 16-bit, 44.1/48 kHz sample rate for high-definition audio.
- The adapter features a volume control to adjust headphone volume. A mute button silences the microphone audio when you do not wish to be heard.
- The adapter provides plug-in power for microphones that need power.
- A mute light illuminates red when the microphone is muted. The USB light illuminates green when the adapter is properly connected to a powered USB port and when the microphone is not muted.
- The adapter is compatible with Windows 2000 or later, Mac OS X, iOS, and Android devices with a USB Type-C connector. It is plug-and-play, so drivers are not necessary.
Specifications
| Interface | |
| Channels of I/O | Analogue / USB: 1 Input / 1 Output |
| Max Sample Rate/Resolution | 48 kHz / 16-Bit |
| Input Level Adjustment | 1 x Knob |
| Display and Indicators | 1 x LED |
| Connectivity | |
| Host Connection | 1 x USB Type-C (USB 2.0) 1 x USB Type-A (USB 2.0) |
| Analogue I/O | 1 x 1/8″ / 3.5 mm Unbalanced Mic Input 1 x 1/8″ / 3.5 mm TRS Headphone Output |
| Phantom Power | None |
| Digital I/O | None |
| MIDI I/O | None |
| Memory Card Slot | None |
| Performance | |
| Frequency Response | 20 Hz to 20 kHz ±1 dB |
| Headphone Output Power | 13 mW into 16 Ohms |
| SNR | 70 dB |
| Digital Audio | |
| Sample Rates | Up to 48 kHz |
| Bit Depth | Up to 16-Bit |
| Sync Sources | None |
| Compatibility | |
| OS Compatibility | macOS Windows 2000 or Later |
| Mobile Device Compatibility | Android Smartphone iPad Pro |
| Power | |
| Power Requirements | USB Bus-Power |
| AC/DC Power Adapter | None |
