JBL STX825 Dual 15″ Two-Way Speaker

The JBL STX825 Dual 15″ Two-Way Speaker is an excellent choice when the application calls for high performance and simplicity. A pair of STX825s and a single, high-power amplifier is a complete sound system capable of reinforcing bass and kick drum or playing high-level music in clubs and other venues. The STX825 is comprised of two 380 mm 2226H patented Vented Gap Cooled woofers with combined power handling of 1600 watts (continuous). For the high frequencies, the newly designed 2453H 102 mm voicecoil, neodymium compression driver is mounted to a 90° by 50° horn. Bi-amp or full-range passive operation may be selected by means of a recessed, high-current switch mounted on the input plate. For applications requiring suspension, the enclosure is fitted with twelve M10 suspension points.
The enclosure is constructed of top quality birch/poplar laminate plywood and coated in JBL’s rugged DuraFlex finish. The attractive CNC-machined, 14-gauge steel grille wraps around the sides of the enclosure so there are no protruding lips on the front of the box to create acoustical interference. The grilles are internally lined with acoustically transparent foam to provide additional driver protection and give a very professional appearance.
Key Features

Premium passive loudspeaker system
Very high power handling
Dual 380 mm Vented Gap Cooled low-frequency drivers for extended low-frequency output
102 mm voice-coil neodymium compression driver for high-power capacity and very lightweight
90° x 50° coverage
Bi-amplified or full-range passive operation
Twelve M10 suspension points

Specifications

Active or Passive
Passive

Frequency Range
34 Hz to 20 kHz (-10 db)

Frequency Response
42 Hz to 19 kHz ±3 dB

Coverage Pattern
90 x 50 ° nominal

Crossover Type
Bi-amp or passive, externally switchable

Crossover Frequency
1.3 kHz

Power Handling
Passive :
1,600W continuous
3,200W programme
6,400W peak
Bi-amp LF :
1,600W continuous
3,200W programme
6,400W peak
Bi-amp HF :
75W continuous
150W programme
300W peak

Maximum SPL
136 dB SPL peak

Sensitivity
98 dB SPL (1W at 1 m) in passive mode

Low Frequency Driver
2 x JBL 2226H 15″ (380 mm) Vented Gap Cooled woofer

High Frequency Driver
1 x JBL 2453H 4″ (102 mm) voice-coil, neodymium magnet compression driver

Nominal Impedance
Passive: 4Ω
Bi-amp LF: 4Ω
Bi-amp HF: 8Ω

Enclosure
Trapezoidal, 18 mm 13-ply birch/poplar laminate plywood

Enclosure Tuning
Designed for Crown amplifiers and dbx DriveRack

Mounting Options
12 x M10 Suspension Points

Handle or Carrying Type
2 x side handles

Finish
Black DuraFlex finish

Grille
Powder coated, black, 14-gauge perforated steel with acoustically transparent charcoal foam backing

Input Connectors
2 x Neutrik Speakon NL-4

Dimensions (H x W x D)
1,066 x 568 x 573 mm

Weight
51 kg
