Description
Kiloview P2 portable live video encoder offers wireless live streaming directly from your HDMI camera source to any online destination through multi-channels 4g bonding, wifi and wired network. Kiloview P2 encoder lets content creators of all sizes, budgets and markets live stream professional quality HD video directly to any online video provider without a large crew and lots of equipment. P2 encoder has approved by CE,FCC,HDMI,ISO,etc.
- H.264 video encoding
- SDK Provided
- Branded chips
- Multi-channels 4G-LTE bonding
- Removable hot shoe
- Low bandwidth transmission
- Built-in lithium battery
- 1080P HD live streaming
- Full live platforms supported
Reliable & portable video encoding transmission, suitable for a variety of outdoor live broadcast applications.
● Total weight is only 400g (including battery), with hot shoe bracket, it can be mounted on camera for portable application.
● Supports 5 channels bonding including 4 channels 4G-LTE and 1 channel Wifi/Ethernet by USB, transmission bandwidth is greatly expanded to improve the reliability of video wireless transmission.
● Built-in large-capacity lithium battery lasts about 3 hours, it also supports 5-16v external mobile power supply, making continuous working possible.
● Internal cooling fan makes the encoderr adapting to high temperature conditions, stable and reliable operation.
Advanced encoding and transmission technology.
● With branded chips solution together with video dynamic noise reduction and image enhancement technology, it can realize good encoding image under low bit transmission. Good video image can be achieved at 1Mbps@720p, 1.5Mbps@1080p network.
● Advanced video buffering technology, dynamic rate adjustment technology, FEC technology and links aggregation technology to ensure video encoding delay ≤ 67ms and stable transmission.
● Adjustable bit rate from 64kbit/s～40Mbit/s.
Powerful streaming media service function.
● RTP/ RTSP/ RTMP/ HLS/ TS/ Onvif/ SIP and some other streaming media protocols supported for live broadcast on Facebook, YouTube, Ustream, Twitch, Wowza etc or security platform / NVR system.
● SRT supported to ensure secure and reliable transmission.
● Dual stream output, the main code rate up to 1080p60Hz, and the sub-stream supports 720p 60Hz video encoding.
● Capable with customized text and image overlay function, which can be at any position on the screen.
● Voice intercom function (need to deploy voice intercom software).
● With SD/TF card slot, it supports local recording, and supports NAS network storage.
P1/P2 4G Cellular Bonding Video Encoder
Anytime Anywhere
Kiloview P1/P2 video encoder is a professional high-end encoding device specially designed for mobile applications. It adopts KiloLink – Kiloview’s patented algorithm to solve the problem of poor connectivity. It perfectly suits outdoor live streaming and transmission in such scenarios as live events, concerts, sports, field broadcast, emergency spots and more, anytime, anywhere.
Kiloview P1/P2 features ultra-low end-to-end latency (<1s) , meanwhile, it supports voice intercom with Kiloview KIS, it’s also perfect for remote program production or group interaction.
P1 supports SDI input, while P2 supports HDMI input.
Up to 5 Connections Bonding, Stream Like a Pro
2x Internal 4G Cellular + 2x USB 4G Cellular (LAN)+ 1x Wi-Fi (+1*RJ45) supported and it’s free configurable of any desired network.
With the patented bonding algorithm with KiloLink, P1/P2 encoders can automatically balance the data of all connections and adjust the bitrate accordingly to make sure the reliable streaming.
Besides, P1/P2 can support Wi-Fi hotspot for data and file transmission.
Self-Deploy Bonding Cloud with Device Management
It’s Free, Safe and Flexible
Kiloview provides the bonding software for free, it’s available for deployment on your own server or cloud-based server.
With KiloLink Server, you can manage all your registered devices on the server end, such as monitoring device status, preview a stream, parameter settings, firmware updating, port forwarding and so on. Real time connection status and data statistics are also available on server end.
What’s more, it’s easy to manage with a single QR code. All can be managed on your palm.
Portable Design, Born for Outdoor Live Streaming
Ultra-Low Latency for End-to-End Video Transmission
With optimized technology, Kiloview P1/P2 offers an ultra-low latency video streaming experience, which is suitable for remote production, IRL streaming, or audience interaction with high quality. End-to-end latency with 4G-bonding server is less than one-second under normal working conditions.
Voice Intercom Supported
Together with Kiloview Intercom Server (KIS), you can take part in a group intercom with a USB earphone.
Deploying a Kiloview Intercom Server >>Learn More
RTSP, RTMP, SRT, HLS, TS-UDP and more
No matter you are using a single connection or the bonding connection, with Kiloview P1/P2, you can not only stream your video to Youtube/Facebook and other platforms with RTMP(S), but also transmit your video remotely by SRT, and more other workflows using different protocols such as RTSP, UDP and HLS. Outdoor streaming is never so easy.
Multiple Platform Streaming
Kiloview P1/P2 encoder supports streaming to 16 platforms simultaneously by configuring the main and sub stream in the web console, that means you can stream to all the popular platforms with the same content.
(Main stream resolution up to 1080P60, sub stream resolution up to 720P60)
Video Rotate/Crop, and Image Overlay
With FPGA processing unit, it can easily realize the functions of rotating and cropping for vertical/horizontal video which makes it social media friendly. You can also mirror the stream, or adjust the color. Moreover, you can set your overlay image at any position such as adding a logo, text etc.
More Advantages
High-end Chip
5G Customizable
1080P60
Adjustable Bitrate
Integrated IMS
SDK/API Available
USB PTZ Supported
7×24 Running
Applications
Outdoor streaming, remote video production, IRL streaming, news interviewing, emergency conducting, mobile video transmission, cloud video transmission, hospital video transmission and more wireless video transmission situations.
Parameters
| Model No. | P1, P2 |
|---|---|
| Input | SDI (P1): HDMI (P2) |
| Transmission mode | 4G-LTE, WIFI (2.4/5G dual band), Ethernet by USB expansion* |
| 4G bonding capacity | 4 channels of 4G bonding (2 CH internal+ 2 CH external) |
| Video resolution | Up to 1080P60Hz: 1080p23.98/24/25/29.97/30 1080p50/59.94/60 1080i50/59.94/60 720p23.98/24/25/29.97/30 720p50/59.94/60 |
| Video encoding | H.264/AVC, Motion-JPEG |
| Audio encoding | AAC/G.711 |
| Encoding latency | <67ms |
| Media protocol | RTMP/RTSP/SRT/RTP/HLS/TS over UDP, custom for SIP |
| Graphic overlay | User-defined text, image overlay |
| Recording | TF card slot/hard disk by USB expansion for local recording and NAS network storage |
| Management | Android APP/Web |
| Hot shoe | Removable |
| Battery capacity | 3.7V 6800mAh (29.6Wh) |
| Power supply | DC 12V 1A |
| Power consumption | 6.5w |
| Operating temperature | -20~45℃ |
| Dimension | 115*75*35mm (4.53”*2.95”*1.38”) |
| Weight | 400g (14 oz) |
| Support Download | Docs & Firmware |
*Please refer to the table below for supported USB expansion.
