The XP15 is a self powered two way system designed by leading acoustic engineers for indoor portable applications and installations that require powerful performance from a single portable loudspeaker. It features a 15” (380mm)/3” (75mm) voice coil LF drive unit, and a 1” (25mm) exit HF compression driver with a 1.75” (44mm) polyimide diaphragm. With an accurately defined 80° x 50° coverage pattern, it combines very high output capability with exceptional sonic performance and low frequency impact. Its Class D amplifier module delivers 1000W LF + 300W HF peak output to the drivers, which are independently protected by RMS and peak limiters. Onboard DSP functions are controlled by a rotary encoder interface and multi function, easy to use colour display on the rear panel. DSP features include crossover function, a three channel mixer with threeband EQ on each input channel and a choice of three voicing presets and operating modes for flexible operation without external processing. The symmetrical, multi angle enclosure is manufactured from birch and poplar plywood and finished in textured black paint. It is fitted with M8 inserts for eyebolt suspension plus a pole mount socket with a removable cap. Its cloth backed protective steel grille is a spring-fit into the sides of the enclosure for easy access to rotate the HF horn.
BLUETOOTH® CONTROL AND STREAMING OPTION
ADDED FLEXIBILITY AT YOUR FINGERTIPS
The Bluetooth® feature means you can stream directly to the speakers via a phone or tablet without the need for any app. In addition the app – XP Connect – is available providing both audio streaming and control from iOS phones and tablets*. This provides full control of the onboard DSP, mixer and mode functions — enabling access to the mixer EQ, mute and level to optimise the speaker set-up remotely. It also enables two speakers to be linked for stereo playback.
*Search for XP Connect on Apple App Store
High output, self powered two way system
FREQUENCY RESPONSE 55Hz – 20kHz ±3dB -10dB @ 45Hz
DRIVERS LF: 15” (380mm)/3” (75mm) voice coil ferrite motor system
HF: 1” (25mm) exit/1.7” (44mm) voice coil, polyimide dome compression driver
MAXIMUM SPL 125dB continuous / 131dB peak
DISPERSION 80° H x 50° V (user rotatable)
CROSSOVER 2kHz active, 24dB/octave
Audio In/Out
INPUT CONNECTORS 2 x female XLR/ ¼” jack combo
MIC/LINE INPUT IMPEDANCE 8 kO balanced ¼” JACK TS INPUT IMPEDANCE 1 MO unbalanced
MIX OUTPUT CONNECTOR 1 x male XLR
MIX OUTPUT IMPEDANCE 600Ohm balanced
Internal Processing
Input channel EQ 3 band on each channel plus HPF (Ch1/2)
Speaker EQ 3 speaker mode/voicing presets
Protection LF and HF Peak and RMS limiting, amplifier thermal protection
Amplifier
2 channel switch mode, Class D
PEAK OUTPUT POWER 1300W total 1000W LF, 300W HF
AVERAGE EFFICIENCY 89%
COOLING External convection cooled
MAXIMUM AMBIENT TEMPERATURE 35°C for full output
ENCLOSURE Multi angle birch/poplar ply Black textured paint
GRILLE Black perforated steel with scrim cloth backing
FITTINGS 19 x M8 inserts, pole-mount socket, 2 x pocket handles
DIMENSIONS (W) 427mm x (H) 690mm x (D) 407mm
WEIGHT 24kg
ACCESSORIES Eyebolts
