Martin Blackline X12 1 x 12″ + 1″ hf Passive Speaker

The X12 fulfils the requirement for a compact system that can deliver high sound levels, either as a stand alone system or supplemented by a BlacklineX subwoofer. Featuring a 12” (300mm) LF driver unit and a 1” (25mm) exit compression driver on a user rotatable horn, its 80° x 50° dispersion pattern is ideal for medium throw applications.The LF driver has a 2.5” (63mm) voice coil and a high BL motor, while the HF compression driver utilises a 1.75” (44mm) polyimide diaphragm for extended high frequency response. Use with a BlacklineX Series subwoofer will enable the X12 to operate as a dancefloor or sound reinforcement system that is remarkably powerful for its size, as well as being extremely portable.The X12 is constructed from plywood and fitted with a screw free steel grille, M8 inserts for wall brackets and eyebolt suspension, plus a pole mount socket with a removable bung that maintains clean lines in install applications. https://martin-audio.com/downloads/datasheets/X12datasheet. pdfA full range passive two way system, the X12 may be used without a controller. However, the EQ and limiter functions of a controller such as the Martin Audio DX0.5 will maximise its capabilities. When used in conjunction with an X115, X118 or X210 subwoofer, crossover and EQ functions can be performed by the DX0.5, or by an MA Series amplifier with onboard DSP option.Compact, passive two way systemFREQUENCY RESPONSE 62Hz-20kHz ± 3dB, -10dB @ 50HzDRIVER LF: 12” (300mm)/2.5” (63.5mm) voice coil, ferrite motor systemHF: 1” (25mm) exit 1.7” (44mm) voice coil, polyimide dome compression driverRATED POWER 300W AES, 1200W peakRECOMMENDED AMPLIFIER MA2.0, MA3.0, MA5.0QSENSITIVITY 97dBMAXIMUM SPL 122dB continuous, 128dB peakNOMINAL IMPEDANCE 8 ohmsDISPERSION (-6dB) 80° H x 50° V (user-rotatable)CROSSOVER 2.3kHz passiveENCLOSURE Multi angle birch/poplar plyFINISH Black textured paintGRILLE Black perforated steel with scrim cloth backingCONNECTORS 2 x NL4 typePIN CONNECTIONS (INPUT) 1+/1-PIN CONNECTIONS (LINK) 1+/- to 1+/-FITTINGS 20 x M8 inserts, pole mount socket, 1 x bar handleDIMENSIONS (W) 358mm x (H) 574mm x (D) 337mmWEIGHT 17kgOptional ACCESSORIES Wall bracket, eyebolts
