Designed for critical listening in the studio or at home, the PreSonus Temblor T8 Active 8″ Studio Subwoofer complements any full-range monitoring system, and is suitable for use in a variety of applications such as music production, gaming, and home theatre, and more.
The Temblor T8 features an 8″, down-firing, glass-composite woofer which is powered by a Class AB amplifier that delivers 200 watts of power. It has a round, front-firing acoustic port, 1/4″ TRS and RCA main inputs, and 1/4″ TRS and RCA pass-through outputs to connect your top speakers.
The speaker also includes a continuously variable low-pass filter that can be set between 50 Hz to 130 Hz, and also has a switchable high-pass filter that removes content below 80 Hz from the full-range signal sent to your satellite speakers, allowing you to create a seamless crossover transition.
Key Features
- 8-inch, downward-firing, glass-composite low-frequency transducer
- Round, rear-firing, bass-reflex acoustic port
- Polarity invert assures the sub is phase aligned with top speakers
- Internal damping and heat sink
- Integrated rubber feet for stable placement
Specifications
| Inputs | 2x Balanced 1/4″ TRS 2x Unbalanced RCA |
| Outputs | 2x Balanced ¼” TRS (full range with 80 Hz HPF option) 2x Unbalanced RCA (full range with 80 Hz HPF option) |
| Frequency Response | 30 Hz – 200 Hz |
| Low Pass Filter | 50 – 130 Hz (variable) |
| Signal to Noise Ratio | >98 dB (A weighted) |
| THD | 0.05% |
| Amplifier Power | 200 W peak, 100 W RMS |
| Power Consumption | 120 W |
| Amplifier Type | Class AB |
| Max Peak SPL | 104 dB at 1 m |
| Woofer | 8″ glass-composite, downward-firing |
| Port | Rear-firing bass reflex (round) |
| Input Gain Adjustment | -30 to +6 dB |
| Polarity Reverse | 0 or 180° |
| Low Pass Filter | 50 Hz to 130 Hz |
| High Pass Filter | On/off |
| Protection | RF interference
Output-current limiting Over-temperature Turn-on/off transient Subsonic filter External mains fuse |
| Power | 100-120 V ~50/60 Hz or 220-240 V ~50/60 Hz |
| Cabinet | Vinyl-laminated MDF |
| Dimensions | 260 x 320 280 mm |
| Weight | 9.6 kg |
