Great for Live Streaming
Features:
1. Connect multiple dongles to one machine
2. Enable the up/down conversion of video resolution, frame rate and audio sampling rate
3. Support brightness, contrast, hue, saturation, and other screen adjustment functions
4. The HDMI video capture meets UVC standard, support YUV 4:2:2 (YUY2) video output
5. The HDMI video capture meets UAC standard and 48KHz PCM stereo audio output
6. The video processing engine can be updated via firmware without changing the hardware.
7. Automatically detect and de-interlace signals
8. Reliable and Stable: 64MB DDR2 Onboard memory, it can effectively conduct video frame buffer and USB transfer flow control to avoid interruption or error images when the USB transmission bandwidth is occupied.
Pass through 7x24h continuous high load tests in high and low temperatures (0-50 degrees)
9. Easy to Use: No need to install drivers in Windows, Linux, and OS X, real plug and play.
Compatibility:
1. Compatible with various USB 3.0 chipsets (Intel, Renesas, ASMedia, Fresco Logic), compatible with expended USB 3.0 via PCIe Gen1.1 x1
2. Compatible with USB 2.0
3. Compatible operating systems: Windows (7, 8, 8.1), Linux (kernel version 2.6.38 and above), OS X (10.8 and above)
4. Support APIs, such as Windows: DirectShow, DirectSound, Linux: V4L2, ALSA, OS X: QuickTime
5. Support software including Windows Media Encoder (Windows), Adobe Flash Media Live Encoder (Windows, OS X), Real Producer Plus (Windows), VLC (Windows, OS X, Linux), QuickTime Broadcaster (OS X), QuickTime Player (OS X), Wirecast (Windows, OS X) and etc.
Specifications:
| Connection | |
|
Host Interface |
USB3.0, *300-350MB/s throughput USB2.0, *40MB/s throughput |
|
Input Interface |
1 HDMI interface |
|
HDMI Video Input |
1 1080P/60HZ HD HDMI signal |
|
HDMI Audio Input |
1 LPCM audio signal |
| Standard | |
|
HDMI Input Formats |
It meets HDMI 1.4a standard and supports 1080p/60Hz 8-bit, (RGB, YUV) |
|
Output Formats |
Up to 48KHz, 85db, 24-bit |
|
Video Sampling Rate |
HDMI: 165MHz |
|
Audio and Video Capture |
It meets the standards of UVC (USB video class) and UAC(USB audio class) |
|
Output Color Space |
YUY2 |
| Video Processing | |
|
Switch of Color Space |
Hardware Color Switch |
|
Image Scale |
Hardware Scale |
|
Image Adjustment |
The image adjustment of brightness, contrast, hue, saturation |
| Others | |
|
OS Support |
It supports the following operating systems (x86 and x64 versions): Windows 7 Windows Server 2008 R2 Linux (Kernel version 2.6.38 and above) OS X (10.8 and above) |
|
Software Compatibility |
Windows Media Encoder (Windows) Adobe Flash Media Live Encoder(Windows, OS X) Real Producer Plus(Windows) VLC (Windows, OS X, Linux) QuickTime Broadcaster (OS X) QuickTime Player (OS X) Wirecast (Windows, OS X), etc.
|
Pacakge:
1 x HDMI Capture Dongle
1 x USB Cable
